Orion Star™ A326 Tragbares Multiparameter-Tischmessgerät für pH/gel

SKU: T05-STARA3265
Category: Electrochemical measuring instruments
Manufacturers: Thermo Scientific - Equipment LED

2.428,40 €

excl. 19% VAT ,

Delivery time on request
Delivery time: ca. 4 weeks (DE - int. shipments may differ)

Orion Star™ A326 Portable Multiparameter Benchtop pH/Dissolved Oxygen Meter With the Thermo Scientific™ Orion™ Star A326 Portable pH/DO/RDO Meter for high performance in demanding outdoor tests, you can accurately measure pH, dissolved oxygen and temperature Power supply: Universal 50-60 Hz, 100-240 VAC power adapter (sold separately, Cat. No. 1010003) Accuracy (Barometer): ±6mmHg Accuracy (DO, polarographic): ±0.2mg/L or ±2% of reading, whichever is greater Accuracy (RDO): ±0.1mg/L up to 8mg/L, ±0.2mg/L from 8 to 20mg/L, ±10% of reading up to 50mg/L Accuracy (mV): ±0.2 mV or ±0.05% of reading whichever is greater Accuracy (pH): ±0.002 Alarm output: High/low limit alarm, calibration due alarm Backlight option: Yes, selectable Air pressure correction:: 400 to 850mmHg, automatic using built-in barometer or manual entry Battery life: 800 hr. Battery type: 4 AA (included) Calibration: Modifiable pH calibration points, rel. mV (RmV), ORP and temperature Calibration modes: Water-saturated air, air-saturated water, manual (Winkler titration), zero Calibration points: 1 point relative mV (RmV) mode, 1 point ORP mode Calibration points (pH): 1 to 5 Certification/Compliance: CE, TUV 3-1, FCC Class A Data management details: Transfer individual data points, multiple data points in a specified range or all data points to a printer or computer Data points: 5000 with date and time stamp Description: Orion Star A326 pH/RDO/DO portable meter kit with ROSS Ultra Triode low maintenance gel pH/ATC electrode, RDO optical DO sensor, solutions, meter armor and field case Dimensions (L x W x H): 24cm x 10cm x 6. 5cm (9.5 in. x 3.9 in. x 2.6 in.) Contains: Star A326 pH/RDO/DO Meter with Batteries; 8107UWMMD ROSS Gel-filled Epoxy pH/ATC Triode with 3 Meter Cable; 087010MD RDO Optical DO Probe with 3 Meter Cable; 910410 pH 4.01 Buffer Pouches; 910710 pH 7.00 Buffer Pouches; 911010 pH 10. 01 Buffer Pouches; 810001 Orion ROSS electrode storage solution; 01100710 Orion 1413 μS conductivity standard pouches; 911110 rinse solution pouches; Protective armor with electrode holder; Hard carrying case; AA batteries (installed) Inputs: BNC (pH or ORP electrode), pin-tip (reference electrode), 8 pin MiniDIN (ATC temperature probe), 9 pin MiniDIN (RDO optical or polarographic DO sensor with built-in temperature) Isopotential point: 7. 000pH Keypad: Comprehensive with menu-specific function keys and dual purpose scroll/shortcut keys Languages: English, Spanish, French, Italian, German and Chinese; Portuguese and Korean available with software update Logging function type: Automatic data logging in auto-read and timed measurement modes and manual data logging in continuous measurement mode Main memory: Non-volatile memory preserves data log, calibration log and meter settings Procedures: 10 per channel with password protection Percent Saturation Range (Polarographic DO): 0.0 to 600.0 % saturation Percent Saturation Relative Accuracy (RDO): ±2 % saturation ≤ 200 % saturation, ±10 % saturation > 200 % saturation Percent Saturation Resolution (Polarographic DO): 0.1, 1 % saturation Saturation Range (RDO) in %: 0.0 to 500.0 % saturation Percent Saturation Relative Accuracy (DO, Polarographic): ±2 % saturation or ±2% of reading whichever is greater Resolution of saturation in % (RDO): 0.1, 1 % saturation Power supply: 4 AA batteries (included) or universal AC adapter (sold separately) Pressure range: 400 to 850mmHg Pressure resolution: 1mmHg Range (ORP): ±2000.0 mV Range (DO, polarographic): 0.00 to 90.00mg/L Range (RDO): 0.00 to 50.00mg/L Range (relative mV): ±2000.0 mV Range relative humidity: 5 to 85 %, non-condensing Resolution (DO, polarographic): 0.01, 0.1mg/L Resolution (RDO): 0.01, 0.1mg/L Resolution (mV): 0.1mV Salinity factor: 0.0 to 45. 0 ppt, automatic correction using manual entry of sample salinity Stability: Selectable fast, medium, slow or Smart Stability setting; Selectable off or Automatic Smart averaging setting Temperature accuracy: ±0.1°C Operating temperature (Anglo-American): 41°F to 113°F (ambient) Operating temperature (metric): 5°C to 45°C (ambient) Temperature probe calibration: 1 point temperature offset calibration Temperature range (Anglo-American): 22.0°F to 221.0° F Temperature resolution: 0.1°C, 0.1°F Temperature selection: Manual or automatic with ATC temperature probe Warranty: 3 Year Meter Weight (Anglo-American): 1.2 lb. Channels: 2 Display Type: LCD Graphic, Backlit IP Rating: IP 67 Measurement Modes: pH, mV, relative mV (RMV) or ORP with temperature; dissolved oxygen as % saturation or mg/l with temperature Outputs: USB, RS232 Percent Saturation Range Polarographic DO: 0.0 to 600.0 % saturation Range (mV): ±2000.0 mV Range (pH): -2.000 to 20.000 Resolution (pH): 0.1/0.01/0.001 Temperature Range (metric): -5.0 °C° to +105.0 °C° Unit Size: Each Orion Star™ A326 pH/Dissolved Oxygen Portable Multiparameter Meter

Product safety information

Manufacturer information:

Thermo Scientific - Equipment LED

, ,
