PULVERISETTE 1 classic line jaw crusher model 2 200 V/3~ 60 Hz, £ 20379,20

Cookiename	Beispielinhalt	Ablaufzeit
_ga_*	deleted	730 Tage
_ga	GA1.1.8643343795.1726666186	730 Tage

For fast and effective pre-crushing of very hard, hard, medium-hard, abrasive and brittle samples, as well as ferro-alloys. Application Mining and metallurgy, chemistry, geology and mineralogy, glass industry, ceramics, stones and earths. Method of operation The sample is powerfully crushed in the jaw crusher by means of high pressure between a fixed and a movable crushing plate in a closed grinding chamber. The final fineness is simply defined from the outside by the distance between the crushing plates, which can be adjusted in 10 steps. The crushed sample automatically falls down – in case of batchwise crushing into a drawer, in case of continuous operation via a chute into a larger collecting container or for further crushing directly into a FRITSCH Disc Mill PULVERISETTE 13 classic line. The performance features at a glance • very fast, uniform size reduction • max. feed size up to 95 mm, final fineness 1-15 mm, max. throughput 200 kg/h • quick and easy cleaning • Plexiglas cover for visual control of the grinding chamber • extremely robust even for very hard materials • particularly easy crushing plate removal • safe dust-free operation • adjustable crushing plate kinematics for higher final fineness • Can be combined with the disk mill PULVERISETTE 13 classic line • Tested safety (CE mark) • 2-year warranty Equipment Fixed and movable crushing plates and lateral support walls made of hardened steel are part of the standard equipment of FRITSCH jaw crushers and are therefore included in the price of the instruments. Crushing plates and lateral support walls are available in the following materials: hardened steel, stainless steel, chrome-free tool steel, chrome-free steel, manganese steel, carbide tungsten carbide and zirconium oxide. These can be easily exchanged or the jaw crusher can already be ordered with the desired equipment. Fixed and movable crushing plates made of steel with ribbed surface on request. PULVERISETTE 1 classic line Jaw Crusher Model 2

Product safety information

Manufacturer information:

Fritsch

, ,
