Horizontal hinged tube furnace up to 1200°C Resistance wire heating elements embedded in high quality vacuum formed fibre insulation 1200 °C maximum temperature 800 mm heated length 1150 mm tube length under air atmosphere 1400 mm tube length under protective gas atmosphere 125 mm max. Outer tube diameter without working tube 430x1065x575 mm (HxWxD) Outer dimensions of the furnace Digital PID controller (see details in separate item) 220x655x480 mm (HxWxD) Outer dimensions of the control unit 3.16 kW max. power type N Thermocouple 102 kg Weight Connection: 230 V, single-phase, 50 Hz, 3.16 kW The picture shows an item of the same type. Size and equipment may differ from this type. The furnace body is supplied with a separate control unit. For horizontal operation, the furnace body can be placed directly on a table. There is a 2 m connecting cable between the oven body and the control unit, which can easily be unplugged at the back of the control unit. EPC3016P1 with 24 freely programmable segments (e.g. 12 ramps and 12 dwell times) - Self-optimisation - Thermocouple breakage protection - Electronic setting limit - Digital temperature setting - Digital actual and setpoint display - Max. 2 control tracks (e.g. for optional solenoid valves) - Ethernet control unit with 24 programmable segments (e.g. 12 ramps and 12 dwell times) for optional solenoid valves) - Ethernet connection on the rear panel of the control housing To operate the furnace, be sure to order one of the following packages as well - Air package IAP 75x86x1150mm - Protective gas package IAP 75x86x1400mm - Vacuum package (on request) Optional surcharge for CC-T1 of EPC3016P1 (00053272) Digital overtemperature protection (00053325) TS1 12/125/800 EPC3016P1 programmer Medium single zone tube furnace Wire he
